Michell Instruments XTC601 Binary Gas Analyzer

• Thermal conductivity
• Mixture of gases containing: CO2, CH4, Ar, He, N2, H2 or Air
• Selectable from 0-5 up to 0-100% measurement ranges
• Touch screen display
• 0.1% resolution
• ±2% accuracy
• IP66 rated enclosure
• SIL2 Rated: Meets IEC61508 Requirements
• ATEX, IECEx, TC TR Ex & cCSAUS certified hazardous areas

Michell Instruments XTC601 Binary Gas Analyzer is designed to measure the percentage of a selected gas in a binary mix. Using thermal conductivity with high quality thermistors, the sensor is reliable and highly stable. The analyzer is housed in an explosion-proof case and is rated ATEX Cat II for use in hazardous areas. For installation in non-hazardous areas, a general purpose version is available.

Applications for the XTC601 include:

• Hydrogen coolant in electricity turbines
• Product quality in air separation plants
• Syngas production
• Helium recovery
• Fuel cell research
• Gasification
• Product quality such as air in argon for double glazing
• Can be coupled with an XTP601 for measuring oxygen in varying backgrounds
• AR or HE in food and beverage plants
