The Amprobe LH41A AC/DC clamp-on ammeter offers precise low current measurement from 0 to 40 A DC or AC peak with 1 mA
resolution. Amprobe LH41A AC/DC clamp-on ammeters feature auto ranging, data hold and auto power off functions making
the meter extremely easy to use. The Amprobe LH41A ammeter has a CAT III 300 V safety rating.
| Electrical Data | (All accuracies stated at 23°C ±1°C) |
|---|---|
| Measuring range | 0 – 40 A DC or AC pk |
| Autoranging | 4 A/40 A |
| Resolution | 1 mA in 4 A range |
| 10 mA in 40 A range | |
| Basic accuracy | ± 1.3% + 5 digits |
| Temperature coefficient | ±0.05 % of rdg/°C |
| Frequency range | 40 Hz to 400 Hz in AC |
| Overload capacity | 150 A |
| Safety rating | CAT III, 300 V |
